Getinge Maquet PowerLED II Maintenance Manual

6
Inspections
Mechanical inspections
32 / 56
Maquet PowerLEDII
01810 EN 03
WARNING!
Risk of injury
The metal half-rings can be sharp.
The metal half-rings on the spring arm should be handled with care to avoid
any risk of cuts.
Fig.38: Acrobat or Ondaspace spring arm
• Check that the vertical stop is properly ad-
justed.
• Check the balance.
• AC2000: Check the presence of the snap
ring and the replacement periodicity for the
DF version, and the presence of the two
stop screws for the SF version.
• AC2000: Check that the safety ring is in
place with its mounting screw.
• ONDASPACE: Check the presence of the
snap ring and the replacement periodicity.
• ONDASPACE SF: Check that the safety
ring is in place with its mounting screw.
• ONDASPACE DF: Check that the safety
plate is in place with its two mounting
screws.
• Check the correct installation of the covers
and tightening of the screws.
• Check the condition, position and sliding of
the tabs.
Fig.39: Valia spring arm
• Check that the vertical stop is properly ad-
justed.
• Check the balance.
• VALIA SF: Check the presence of the
snap ring and the replacement periodicity.
• VALIA DF: Check the presence of the
snap ring and the replacement periodicity.
• VALIA: Check the correct installation of
the covers, flanges, and the tightening of
the screws.
• VALIA: Check the presence of the flange
covers and screw covers.
• VALIA: Check that the spring arm tabs are
correctly positioned and that there is no
friction noise on the cables.
• Check the position and sliding of the tabs.
