Getinge Maquet PowerLED II Maintenance Manual

6
Inspections
Mechanical inspections
34 / 56
Maquet PowerLEDII
01810 EN 03
WARNING!
Risk of injury
A wrong handling of XHD1 screen holder may result in a hand injury.
Respect safety indications on the product.
.nim
mm 56
Fig.43: XHD1 monitor mount
• XHD1: Check that the slip ring is lowered all the way.
• XHD1: Check that the cable protective sheath is installed properly and with the required 65-
mm minimum clearance.
• XHD1: Check that the grey cover is closed.
• XHD1: Check that the caps at each end of the rail are fully inserted.
• XHD1: Check the ground connections.
Fig.44: Monitor
• Check that there are no cracks or
scratches.
