General Information
01-24 79032996 A Rev.
Radiator Coolant Check level of coolant in radiator coolant
recovery tank, with combine parked on level
ground, and add coolant if necessary
Use solution of 50% water and 50%
diesel type low silicant antifreeze. Do
not use Organic Acid type antifreeze.
Radiator Core and
Rotary Screen Air Intake
Check to ensure screen and radiator core are
clear of chaff and dust
Check twice daily in extremely dusty
conditions. Check that screen is free
to turn before starting engine.
Shoe Grain Pan Check for buildup of material
Transverse Fan Check for buildup of dirt or trash
Wheel Lug Nuts and
Bolts
Check torque every 10 hours or until they
remain tight
10 Hour Maintenance
Component Action Required General Information
50 Hour Lubrication
Component Action Required General Information
Jackshaft Drive Idler Hub Lubricate one fitting
Bin Unloader Elbow (turret
only)
Lubricate one fitting One fitting at top of unloader (turret
only)
Fan Drive Idler Lubricate one fitting One fitting behind fan drive.
Rear Feed Conveyor
Drive Idler Hub
Lubricate one fitting One fitting behind right front tire.
Jackshaft Drive Idler Lubricate one fitting One fitting between elevators.
Axle Pivot Lubricate two fittings One fitting each side of combine, in
front of rear axle.
Separator Drive Idler Hub Lubricate one fitting One fitting front of clean grain elevator.
Bin Unloader Auger
Universal Joint
Lubricate one fitting One fitting inside elbow - Swivel only.
Bin Unloader Auger Inner
Bearing
Lubricate one fitting One fitting inside unloader tube
housing.
Bin Unloader Jackshaft
Idler Hub
Lubricate one fitting One fitting left side of combine.
Swing Hydraulic Cylinder Lubricate one fitting One fitting near unloader.
Tie Rod Ball Socket Lubricate one fittings One fitting on each end of rear axle.
Wheel Spindle Lubricate one fittings One fitting on each end of rear axle.
Pivot Drive Idler Hub Lubricate one fittings One fitting on each side of feeder
house.
Feeder Housing Drive
Idler Hub
Lubricate one fitting One fitting on left side of feeder house.
Bin Unloader Elbow Pivot Lubricate one fitting One fitting on top of elbow - Turret
only.
Unloader Auger Outer
Bearing
Lubricate one fitting One fitting outer end of unloader tube.
Tailings Drive Idler Lubricate one fitting One fitting right side of combine.
Hydro Drive Idler Hub Lubricate one fitting One remote lube line behind engine
near oil drain hose.
