General Motors Tech2 User Guide
88
View Captured Data
Selecting View Captured Data from the Tech2 Main Menu results in the selections shown
below.
F2: VIEW CAPTURED DATA
↓ ↓
Capture Info Snapshot
↓ Select Items, Plot, Select Frame, AutoReverse, Stop, Auto Forward
F0: DTC Information First Frame, Trigger Frame, Last Frame, Units, Previous Frame,
F1: Freeze Frame / Failure Records Next Frame DTC, Previous DTC-Chg, Next DTC-Chg
Live Plot - Change Min/Max, Zoom In-Out
Tool Options
Selecting Tool Options from the Tech2 Main Menu gives you the Tool Options menu,
leading to 10 major selections, as follows:
F3: TOOL OPTIONS
↓
F0: Set Clock
F1: Set Screen Contrast
F2: Set Units
( Metric or English )
F3: Self Test
F4: Set Training Center Mode
( Instructor or Student )
F5: Programming Tech2
F6: Set Communication By-Pass Mode
F7: Make Duplicate PCMCIA Card
F8: Set Language
F9: CANdi Diagnostics
These features—described in more detail on the following pages—are useful for controlling
various Tech2 settings including the self tests and CANdi diagnostics.
