Page | 81
VIII.i Travel quality
Check the quality of the car traveling on all floors (both upward and downward).
VIII.j Emergency and / or inspection trap-doors and doors
Check that the doors and / or trap-doors are not damaged and that the opening and closing
are done without friction.
Check that the door or trap-door closing electrical contacts are clean and properly working.
IX. MRL
-
S
YSTEMS WITH THE MACHINES ROOM IN THE WELL
IX.a Upper car stop mechanical device
Check that the upper car stop mechanical device (UCSMD) has a regular and easy movement
and that all the fixing bolts are are properly tightened.
Check that the electrical safety contact (SBCS) is properly fixed and working:
- The security chain is closed: If the device is in non-active position
- The security chain is open:
- If the device is in position active
- If the device returns to non-active position after it has been activated.
(System reset required).
IX.b Lower car stop mechanical device
Check that the lower car stop mechanical device (LCSMD) has a regular and easy movement
and that all the fixing bolts are are properly tightened.
Check that the electrical safety contacts (SBCA and SBCRn) are properly fixed and working:
- The security chain is closed: If the device is in non-active position
- The security chain is open:
- If the device is in position active
- If the device returns to non-active position after it has been activated.
(System reset required).
Check that the pre-activated car stop device (AMI) and its connecting levers have a regular and
easy movements and that their locking bolts are properly tightened.
Check that the electrical safety contacts (SPR and SPR1) are properly fixed and working
- The security chain is closed: If the parachute bar is in non-active position
- The security chain is open:
- If the parachute bar is rotated in active position
- If the parachute bar returns to non-active position after it has been activated.
(System reset required).
Check that the intervention device (AMI), when powered, reaches the non-active position.
Check that the electrical contact to control the position (R and A) are properly fixed and
working.
Or
Check that the lower car stop mechanical device (LCSMD) has a regular and easy movement
and that all the fixing bolts are are properly tightened.
Check that the electrical safety contacts (SBCA and SBCRn) is properly fixed and working:
- The security chain is closed: If the device is in non-active position
- The security chain is open:
- If the device is in position active
- If the device returns to non-active position after it has been activated.
(System reset required).
Check
- That the cables in the sheaths run properly and, if necessary, lubricate them.
- That the handles and ends of the cable are securely fastened.
