Goblin 420 - Page 37

Main Frame
(H0531-S)
- 1 x Main Frame.
Vertical Fin
(H0532-S)
- 1 x Vertical Fin.
- 2 x Finishing Washer M3.
- 2 x Head Cap Screws M2.5x6.
- 2 x Head Cap Screws M2.5x10.
Anti-Rotation Guide
(H0533-S)
- 1 x Anti-Rotation Guide.
- 2 x Head Cap Screws M2.5x6.
Battery Tray
(H0536-S)
- 1 x Battery Tray.
- 1 x Battery Straps.
- 1 x Double Sided Tape .
Uniball M2 Female
(H0537-S)
- 2 x Uniball M2 Female.
Uniball M2 Male
(H0538-S)
- 5 x Uniball M2 Male.
- 1 x Battery Block.
- 1 x Button Cap
Screws M2x5mm.
Canopy Nut
(H0542-S)
- 2 x Canopy Nut.
- 2 x Set Screw M4x20mm.
Yellow/Blue Canopy
(H0544-S)
Red/Black Canopy
(H0545-S)
Yellow Tail Boom
(H0815-S)
Red Boom
(H0547-S)
Plastic Servo Support
(H0548-S)
- 1 x Plastic Servo Support.
- 1 x Head Cap Screws Shoudered
M2.5x18mm.
Tail Blade 70
(H0554-S)
- 2 x Plastic Servo Support.
Linkage Rod M2
(H0561-S)
- 2 x Linkage Rod M2x22mm.
- 4 x Plastic Ball Link M2.
FBL Support
(H0564-S)
- 1 x FBL Support.
- 2 x Head Cap Screw M2.5x8.
Tail Damper
(H0567-S)
- 2 x Tail Damper.
- 1 x Yellow Canopy.
- 1 x Canopy Edge Protection.
- 2 x Canopy Grommet.
- 1 x Red/Black Canopy.
- 1 x Canopy Edge Protection.
- 2 x Canopy Grommet.
- 1 x Yellow Tail Boom.
- 1 x M8 Carbon Block.
- 2 x Locking Element Tail.
- 1 x Double Sided Tape [HA034].
- 1 x Red Tail Boom.
- 1 x M8 Carbon Block.
- 2 x Locking Element Tail.
- 1 x Double Sided Tape [HA034].
- 1 x Double Sided Tape [HA033].
- 1 x Metrix Hex Nylon Nut M8.
- 1 x Metrix Hex Nylon Screw M8.
- 4 x Metrix Hex Nylon Nut M2.5.
Boom Accessories
(H0535-S)
- 1 x M8 Carbon Block.
- 2 x Locking Element Tail.
- 1 x Double Sided Tape [HA034].
- 1 x Double Sided Tape [HA033].
- 1 x Metrix Hex Nylon Nut M8.
- 1 x Metrix Hex Nylon Screw M8.
- 4 x Metrix Hex Nylon Nut M2.5.
Battery Block
(H0539-S)
Tail Spacer KIT
(H0540-S)
- 2 x Washer
3x 4.75x0.5.
- 2 x Washer
4.5x 5.9x0.5.
- 2 x Washer
2x 4.5x0.5.
- 2 x Oring ID=2.9, S=1.78.
- 2 x Head Cap Screw M2x6mm.
Tail Fin and Landing Gear Stickers
(H0565-S)
- 2 x Tail Fin Stickers.
- 2 x Landing Gear Stickers.
- 1 x FBL Support.
- 2 x Head Cap
Screw M2.5x8mm.
FBL Support
(H0564-S)
Linkage Rod M2
(H0561-S)
- 2 x Linkage Rod M2x22.
- 4 x Plastic Ball Link M2.
- 4 x Tail Servo Spacer.
Tail Servo Spacer
(H0572-S)
- 1 x Plastic Servo Support.
- 1 x Socket Head Cap
Screws M2.5x18mm.
Plastic Servo Support
(H0548-S)
- 1 x Double Sided Tape [HA033].
- 1 x Metrix Hex Nylon Nut M8.
- 1 x Metrix Hex Nylon Screw M8.
- 4 x Metrix Hex Nylon Nut M2.5.
Yellow Canopy
(H0816-S)
Aluminum Tail Belt Guide
(H0568-S)
- 1 x Aluminum Tail Belt Guilde Set.
Canopy Lock
(H0543-S)
- 2 x Canopy Lock.
- 1 x Front Tail Pulley Assembly.
- 1 x Head Cap Screws Shoulder
M2.5x15.
- 3 x Head Cap Screws M2x8mm.
Front Tail Pulley
[H0620-S]
Page 35
Chapter 19, Spare Parts
