Goblin urukay - Chapter 5, Transmission Assembly; Bag 3 Assembly Steps

Bearing
10x 19x5mm
(HC422-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
......x1
Finishing
Washer M3
(H0007-S)
Bearing
10x 19x5mm
......x1
Servo Support
(H0010-S)
Bearing
12x 24x6mm
(HC426-S)
Bearing
12x 24x6mm
(HC426-S)
Swash plate
Anti-Rotation Guide
(H0152-S)
Column
(H0018-S)
Socket Head Cap Screw
M3x10mm
......x2
......x1
......x3
Button Head Cap
ScrewM3x4mm
(HC038-S)
Antenna Guide
(H0050-S)
Main Structure
(H0009-S)
Bearing Support Assembly
(H0024-S)
......x1
......x4
Button Head Cap Screw
M3x4mm
......x1
Flat Head Cap Screw
M2.5x5mm
(HC128-S)
Socket Head Cap Screw
M3x8mm
Socket Head Cap
Screw M3x8mm
(HC050-S)
Bearing
12x 24x6mm
......x3
Socket Head Cap
Screw M3x10mm
(HC056-S)
Column
(H0018-S)
Bearing
10x 19x5mm
Bearing
12x 24x6mm
Socket Head Cap Screw
M3x10mm
Flat Head Cap Screw
M2.5x5mm
Bearing
10x 19x5mm
(HC422-S)
Note:
Socket Head Cap
Screw M3x10mm
(HC056-S)
Note:
You must be put strong main gear (H0320-S)
before you put 3 column on main structure
Bag 3
Page 9
Chapter 5, Transmission Assembly
