[HC200-S] [HC206-S]
- 10 x Metric Hex Nylon
Nuts M2,5H3,5.
[HC212-S] [HC218-S] [HC230-S]
- 1 x Main Belt.
- 3 X Thread Rods
M2.5x40mm.
[HC242-S][HC451-S] [HC325-S][HC232-S] [HC309-S]
[HC411-S] [HC420-S][HC414-S] [HC418-S]
- 4 x Bearings
5x
10x4mm.
- 2 x Flanged Bearings
6x
13x4mm.
- 2 x Flanged Bearings
8x
12x3.5mm.
- 2 x Bearings
10x
15x4mm.
[HC410-S]
- 4 x Flanged Bearings
3x
7x3mm.
- 4 x Flanged Bearings
2.5x
6x2.6mm.
- 4 x Tail Oring Damperner.
- 2 x Spring 5,8/df 0,3/LL 9.
- 1 x Spring 8 /df 0,5 / LL 8.
- 2 x Spring 3 /df 5 / LL 12.
[HC400-S][HC335-S]
- 1 x Motor Belt
240-3MGT 19mm.
[HC402-S][HC315-S]
[HC422-S]
[HC426-S] [HC438-S]
- 4 x Bearings
10x
19x5mm.
[HC430-S] [HC435-S]
- 2 x Rad Bearings
30x
37x4mm.
- 2 x Thrust Bearings
5x
10x4mm.
[HC442-S]
- 2 x Cable Pass.
- 1 x Canopy Mousse.
- 2 x Hex Wrenches 2,5.
- 1 x Foam Blade Holder
[HA006-S]
[HA002-S]
- 1 x One Way Bearings
10x
14x12mm.
[HA010-S]
[HA001-S]
- 4 x Flanged Bearings
5x
9x3mm.
- 2 x Bearings
12x
24x6mm.
- 10 x Metric Hex Nylon
Nuts M3H4.
- 10 x Metric Hex Nylon
Nuts M4H5.
- 5 x Metric Hex Nylon
Nuts M5H4.5.
- 5 x Shims
Ø10xØ16x1mm.
- 5 x Shims
Ø10xØ16x0.2mm.
- 1 x Carbon Rod
Ø4xØ2,5x752mm.
- 2 x Plastic Ball Linkage.
- 2 x Thread Rod M2.5x40mm.
- 2 x Thrust Bearings
10x
18x5.5mm.
[HA025-S]
- 2 x Velcro Battery Strap.
- 4 x O-ring 3050.
- 2 x Wrench Tool M8,M6.
[HA016-S] [HA024-S]
Page 44
Chapter 18, Spare Parts
