Definition of Terms Referring to
ATOS COMPACT SCAN 300 and 500
Information About the Sensor
Page 10 (40)
atos_cs_rev01_en_rev-c 2012-09-03
4.2 Definition of Terms Referring to
ATOS COMPACT SCAN 300 and 500
4.3 Definition of Terms Referring to ATOS COMPACT SCAN SO
Camera angle
Measuring distance (from ATOS label
to the center of the measuring volume)
Camera lens right R
Camera lens left L
Center of the measuring volume
Height H (measuring volume)
Width W (measuring volume)
Length L (measuring volume)
Projector lens P
Camera position (approx. distance in mm)
Camera angle
Measuring distance (from ATOS label
to the center of the measuring volume)
Camera lens right R
Camera lens left L
Center of the measuring volume
Height H (measuring volume)
Width W (measuring volume)
Length L (measuring volume)
Projector lens P
Camera position (approx. distance in mm)
