GOM ATOS COMPACT SCAN 5M - Mounting Direction of Sensor on Locking Mechanism

Operation of 3D Ball Head
Sensor Fixture
Page 15 (40)
atos_cs_rev01_en_rev-c 2012-09-03
Functional principle of the clamping mechanism
You may adjust the clamping force any time with the knurled thumb
screw g .
7.2.2 Mounting Direction of Sensor on Locking Mechanism
Mounting direction of sensor
g
