Changing the Camera Positions (Step by Step)
Sensor Setup
Page 18 (40)
atos_cs_rev01_en_rev-c 2012-09-03
All camera supports have factory-adjusted stops for the required
camera angles.
Never loosen these stops!
8.3.1 Initial Situation: Sensor in Position 300
ATOS COMPACT SCAN sensor without connection cable (front view)
8.3.2 Loosen Cameras from Support
View from below
