Goodwe SBP Series User Manual

04 OTHER User Manual V1.5-2021-01-21
29
Technical Data GW3600S-BP GW5000S-BP
Battery Input Data
Battery Type
*1
Li-Ion Li-Ion
Rated Battery Voltage (V) 48 48
Battery voltage range (V) 40~60 40~60
Max. Charging Voltage (V) ≤60 (Congurable) ≤60 (Congurable)
Max. Charging Current (A)
*1
75 100
Max. Discharging Current (A)
*1
75 100
Max charge power (W) 3500 4700
Max discharge power (W) 3900 5300
Battery Capacity (Ah)*2 50~2000 50~2000
Charging Strategy for Li-Ion Battery Self-adaption to BMS Self-adaption to BMS
AC Input Data (On-grid)
Nominal Apparent Power Output to
Utility Grid (VA)
3680 5000
Nominal Power Output to Utility Grid
(W)
3680 5000
*3
Max. Apparent Power Output to Utility
Grid (VA)
*4
3680 5000
Nominal Apparent Power from Utility
Grid (VA)
7360 9200
Max. Apparent Power from Utility Grid
(VA)
7360 9200
Nominal Output Voltage (V) 230 230
Output Voltage Range (V) 0~300 0~300
Nominal Output Frequency (Hz) 50/60 50/60
AC Grid Frequency Range (Hz) 45~65 45~65
Nominal Output Current (A) 16 21.7
Max. AC Current Output to Utility Grid
(A)
16 22.8
Max. AC Current From Utility Grid (A) 32 40
Inrush Current(peak and duration) (A) 100A,20us 100A,20us
4.4 Technical Parameters
