Switch disk mode:
The RAID card supports switching between the following three disk modes:
1. Unconfigured Good: Indicates that the physical disk is normal and can be used to configure RAID or
hot spare disks.
2. Unconfigured Bad: Indicates that there is residual RAID information on the physical disk and needs to
be cleared manually.
3. JBOD: Just a Bunch Of Disks, it only concatenates the disks together for capacity expansion, but does
not have the RAID function.
Here is an example of switching from Unconfigured Good mode to Unconfigured Bad mode.
1. As shown in Figure 6-26, select Drive Management on the RAID card configuration interface, and press
Enter.
Figure 6-26 RAID card configuration interface
Figure 6- 26
2. The interface shown in Figure 6-27 is displayed, select the disk to be configured, and press Enter.
Figure 6-27 Drive Management management interface
