Short press this button in the power-on state to start the machine.
The UID button/indicator is used to conveniently locate the server to
be operated. The UID button can be manually pressed or the BMC
command can be remotely controlled to turn the light off or on.
Description of UID indicator:
Blue (on/flashing): Indicates that the server is located.
Off: Indicates that the server is not located.
UID button description: Short press this button to turn on/off the
positioning light.
Reset restart
server button
Press to restart the server
Blinking green light: The hard drive is operating normally
System alarm indicator. Including system alarms, fan alarms, power
supply alarms, etc., which can be viewed through the IPMI
management software
Network port
connection
status
indicator
Corresponds to the Ethernet port indicator of the NIC card.
Green (on): Indicates that the network port is connected normally.
Off: Indicates that the network port is not in use or is faulty.
Note: Corresponding to the two 1GE network ports on the
motherboard.
Network port
connection
status
indicator
Corresponds to the Ethernet port indicator of the NIC card.
Green (on): Indicates that the network port is connected normally.
Off: Indicates that the network port is not in use or is faulty.
Note: Corresponding to the two 1GE network ports on the
motherboard.
Table 1- 13
2.4.2 Rear Panel Components
