Gooxi SL101-D04R-G3 - System Components Description

15
Figure 2- 1
2.3 Introduction of system components
 1U4 bay model
Product
name
SL101-D04R-G3
Processor
Supports one or two 3rd Generation Intel
®
Xeon
®
Scalable processors
MB model
G4DCL
Memory
Supports DDR4 RDIMM/LRDIMM server memory;
memory frequency supports 2400/2666/2933/3200MHz ;
Single CPU supports 8 DDR4 channels, each channel supports 2 DIMMs, and supports a
total of 32 DDR4 slots; single capacity: 16GB, 32GB, 64GB, 128GB, 256GB , and the
whole system supports a maximum memory capacity of 12TB
Note: In order to make the system more stable, it is recommended to use the AVL
MEMORY LIST
PCIe
expansion
Riser1: 1* PCIe4.0x16; Riser2: 1* PCIe4.0x16
Hard drive
Front 4 hot-swap 3.5/2.5-inch SAS/SATA hard drives
M.2 SSD
M.2 x 2 (NVMe protocol 2280)
LAN
On-board 2 Gigabit RJ45 data LAN ports
External
port
Front Port: 2 USB3.0, 1 VGA
Rear port: 1 VGA , 1 COM port , 2 USB3.0 , 1 RJ45 Gigabit management LAN port, 2
Gigabit RJ45 LAN ports
Management
On-board iBMC management module, supports IPMI, SOL, KVM Over IP, virtual media
and other management features
Fan
Supports 7* 7056 fans
