MDE-LEDI-NETWORK-TDS-4099V3.0
►
3G1 antenna time shift configuration switch
SW1
without
DST
DST
TIME OFFSET
US
EU
AU
1/2h
+
-
8h
4h
2h
1h
Positions
1
2
1
2
1
2
1
2
3
4
4
5
6
7
8
OFF
X
X
X
X
X
ON
X
X
X
X
X
X
X
X
X
X
GPS antenna characteristics
► Maximum length of each screened two-core cables: 100m
► Works anywhere in the world.
6.3. AFNOR-NFS-87500 / IRIG-B OUTPUT
The AFNOR-NFS-87500 / IRIG-B time code is delivered through a 4-pin connector.
A signal is available between the 1
st
terminal (left) and the second terminal. A second signal
identical to the first one is available between the 3
rd
and 4
th
terminal (right).
6.4. SERIAL IMPULSION OUTPUT
Impulsion signal is delivered through a 4-pin connector.
A signal is available between the 1
st
terminal (right) and the second terminal A second signal
identical to the first one is available between the 3
rd
and 4
th
terminal (right).
