7.3. POLARISED MINUTE PULSES
The server transmits a 24V impulse signal on a specific electric cable in series or in parallel
to the receiving clock. It delivers a current of 1A for clocks that use an average of 8mA. The
pulse output is active as soon as synchronisation is effective. On this output, it is also
possible to deliver a 24V DCF frame via a 1 pair cable.
► “Output” Page
