27
3
Line the coupler screws with the holes in the rail and loosen them with the 4 mm Allen wrench
until they press rmly against the inside of the rail.
4
Slide one of the ratcheting rail sections onto the other side of the rail coupler.
Use the 4 mm Allen wrench to loosen (turn counter-clockwise) the coupler screws inside the rail
until they press rmly against the rail.
2
Ratchet Rail
Section
Full Frame Assembly
Installing the Rails (Continued)
