42
Crib Frame Assembly
Use two M8 x 16 mm SBHCS screws to attach the right frame leg to the other side of the
table section. Tighten with the 5 mm Allen wrench.
3
Building the Table (Continued)
2
Use two M8 x 16 mm SBHCS screws to attach the left frame leg to the underside of the
table section. Tighten with the 5 mm Allen wrench.
M8 x 16 mm
SBHCS (x2)
Left Frame Leg
Table Section
M8 x 16 mm
SBHCS (x2)
Right Frame
Leg
Install the corner braces onto the front of the left and right frame legs with eight M8 x 16 mm
SBHCS screws and the 5 mm Allen wrench.
4
Corner Brace (x2)
M8 x 16 mm
SBHCS (x8)
Note: Keep tables and legs as square as possible while attaching braces.
To Next Page
