88
Installation Instructions
Part Four | Repairs and Diagnostics
1. Power o the machine and raise the needle
to the highest position using the hand
wheel.
Hand Wheel
1
1. Remove the needle plate (see page 78).
2. Remove the bobbin case from the hook
assembly (see page 28).
3. Turn the inside part of the hook assembly
(shown in blue) so that the positioning
guide is at the highest point.
4. Slide the nger of the hook holder
into the middle of the hook assembly’s
positioning guide (shown in blue).
Attach loosely with the hook holder screw.
Do not tighten.
Hook Assembly
Positioning Guide
2
3
4
5
6
Hook Holder
Finger
Reinstalling the Hook Holder (continued)
To Next Page
