14
Parts & Tools Needed:
Part Three | Out of Box Assembly
Instructions
Take the following steps to install and adjust the handlebars:
1. Take the handlebar assembly from the
second level of the packaging.
1. With the 4 mm T-handle Allen wrench,
remove the handlebar clamp screw to
open the handlebar clamp.
1. Slide them into the slot so that the cables
are on the bottom.
The handlebar clamp opens.
1 2
3
Cables
Handlebar
Assembly
T-handle Allen
Wrench 4 mm
4 mm
Handlebar
Assembly
Task 3 - Installing the Handlebars
Handlebar
Clamp Screw
To Next Page
