26
Part Three | Preparing to Quilt
Task 8 - Winding a Bobbin (continued)
1. Run the thread through the thread mast
guide loop directly above the thread cone.
1. Pass the thread underneath the left side
of the thread guide. Move it through the
middle of the thread guide back to the front
and then underneath the right side of the
thread guide.
1. Pull the thread through the hole in the
tensioner thread guide and then around
the back of the bobbin thread tensioner,
between the two discs.
1
2
3
1. Winding stops automatically when the
bobbin is full. Cut the bobbin away from the
thread cone using the thread cutter near
the bobbin winder.
1. Wrap the thread clockwise around the empty
bobbin. Press start when ready.
5
4
Guide Loop
Thread Mast
Thread
Cutter
Thread
Guide
Thread
Guide
Start Button
The bobbin thread should appear neat and
smooth. See Bobbin Wind Troublsehooting
Guide for more info.
