79
Installation Instructions
To install the needle plate onto the quilting machine, take the following steps:
Part Four | Maintaining the Machine
4. Slowly lower the needle with the hand
wheel. The needle should slide into the
center hole without contacting the needle
plate.
5. Place the two needle plate screws (shown
in gray) into the plate. Make sure the needle
plate is centered around the needle, and
then tighten the screws with the at-head
screwdriver.
2. Slide the needle plate (shown in gray) onto
the machine.
3. Align the screw holes on the needle plate
with those on the machine.
1. Power o the machine. Raise the needle to
the highest position using the hand wheel.
1
2
3
4
5
Hand Wheel
Reinstalling the Needle Plate (continued)
1. Adjust height as needed (see page 75).
Hopping Foot
Height Tool
6
To Next Page
