58
Instructions
The machine’s bobbin cam is set so the bobbin will wind completely before the winder shuts o. To
change how much the bobbin lls before the winding stops, take the following steps:
1. Power o the machine.
2. Place an empty bobbin onto the bobbin stand and ip the bobbin cam toward the bobbin. This
will help estimate how far to adjust the bobbin cam.
Adjusting the Bobbin Cam
Parts & Tools Needed:
• 1.5 mm Allen Wrench (not included)
3. Loosen the set screw on the bobbin cam with a 1.5 mm Allen wrench until the top of the
bobbin cam twists freely.
4. Point the set screw toward the bobbin to decrease the amount the bobbin will ll before the
winder shuts o. Point the set screw away from the bobbin to increase the ll amount.
5. After choosing the desired distance, tighten the set screw with a 1.5 mm Allen wrench.
Set Screw
Point toward bobbin to
decrease ll.
Point away from bobbin
to increase ll.
Maintaining the Machine
1
4
2
3
5
To Next Page
