Grace Qnique 19 User Manual

62
Removal Instructions
To remove the hopping foot for maintenance or to adjust the hopping foot angle, take the following
steps:
1. Power o the machine.
2. Rotate the hand wheel to lift the needle from the inside of the hopping foot.
3. Use the 3 mm Allen wrench to remove the hopping foot screw.
Hopping Foot
Screw
The hopping foot should now slide free from the presser bar.
Hopping Foot
Maintaining the Machine
1
2
3
Adjusting the Hopping Foot (Continued)
