Grace Qnique 19 User Manual

60
Rotation Instructions
The hopping foot can be rotated to improve line of sight. To rotate the hopping foot, please take the
following steps.
1. Power o the machine.
2. Rotate the hand wheel to lift the needle
from the hopping foot.
Maintaining the Machine
Hopping Foot
Screw
Hopping Foot
3. Use the 3 mm Allen wrench to remove the
screw holding the hopping foot.
4. Slide the hopping foot from the presser
bar.
5. With the 3 mm Allen wrench, loosen the
collar screw that holds the hopping foot
collar to the presser bar.
Hand
Wheel
6. Drop the hopping foot collar below the
presser bar and turn it to the desired
position.
1
4
2
3
5
6
Collar Screw
Hopping Foot
Collar
The hopping foot can be set to two positions:
Adjusting the Hopping Foot (Continued)

Grace Qnique 19 Specifications

General

Brand	Grace
Model	Qnique 19
Category	Sewing Machine
Language	English
