Setup
20 3B0070C
7. Fill TSL fill port with TSL to prevent
premature packing wear. Do this daily or
each time you spray.
a. Place the TSL bottle nozzle into
the top center opening in the grill
at the front of the sprayer.
b. Squeeze bottle to dispense
enough TSL to fill the space
between the pump rod and
packing nut seal.
8. Make certain ON/OFF switch is OFF and
the pressure control is in the OFF
position.
9. Plug power supply cord into a properly
grounded electrical outlet.
10. Turn prime valve to the down position.
11. Place suction tube with drain tube in
grounded metal pail partially filled with
flushing fluid. See Grounding, page 16.
NOTE: Check flushing fluid for compatibility
with material that is to be sprayed. A
secondary flush with a compatible fluid may
be necessary. Water for latex paint or mineral
spirits for oil-based paint.
