Setup
3B0070C 19
Setup
When unpacking sprayer for the first time or
after long term storage perform setup
procedure. When first setup is performed
remove shipping plug from fluid outlet.
Sprayer is equipped with Pump Armor
™
in
the system.
1. Connect Graco airless hose to fluid
outlet. Use two wrenches to tighten
securely.
2. Connect other end of hose to gun.
3. Use two wrenches to tighten securely.
4. Engage trigger lock.
5. Remove tip guard.
6. When unpacking sprayer for the first
time remove packaging materials from
inlet strainer. After long term storage
check inlet strainer for clogs and debris.
