Operation
24 3B0070C
Operation
Spray Tip Installation
1. Perform Pressure Relief Procedure,
page 17.
2. Use spray tip (A) to insert OneSeal
™
(B)
into tip guard (C).
3. Insert Spray Tip.
4. Screw assembly onto gun. Tighten.
Performance Modes
The sprayer is equipped with two
performance modes.
LP (Low Pressure) Mode (L): 50-2,000 psi.
This mode is best used with Low Pressure
Switch Tips (FFLP, LP, and WRLP)
HP (High Pressure) Mode (H): 600-3,300
psi. This mode is best used with any Switch
Tip.
To select or change the performance mode,
see Selecting Performance Modes, page
30.
To avoid serious injury from skin injection
do not put your hand in front of the spray
tip when installing or removing the spray
tip and tip guard.
