Technical Specifications
3B0070C 67
Technical Specifications
US Metric
Sprayer
Maximum fluid working pressure 3300 psi 228 bar, 22.8 MPa
Maximum Delivery
695 XT 1.05 gpm 4.0 Ipm
795 XT/Mark IV XT 1.2 gpm 4.5 lpm
1095 1.3 gpm 4.9 lpm
Mark V XT
1.5 gpm
5.6 lpm (110V) / 4.6 lpm (230V) / 4.7
lpm (220V)
Mark VII NA 6.4 lpm
Maximum Tip Size
695 XT 0.031
795 XT 0.033
1095 XT
110-120V Models 0.037
220-240V Models 0.035
Mark IV XT 0.033
Mark V XT
110-120V Models 0.039
220-240V Models 0.035
Mark VII XT 0.041
Fluid Outlet npsm
695 XT, 795 XT, 1095 XT 1/4 in.
Mark IV XT, Mark V XT 3/8 in.
Mark VII XT 1/2 in.
Generator Minimum 5000 W
Power Requirements
695 XT 100-120 VAC, 15 Amp. 50-60 Hz 220-240 VAC, 10 Amp. 50-60 Hz
795 XT, Mark IV XT, 1095 XT, Mark
V XT
100-120 VAC, 20 Amp. 50-60 Hz
220-240 VAC, 10 Amp. 50-60 Hz
Mark VII XT N/A 220-240 VAC, 16 Amp. 50-60 Hz
Ambient Rating 32-108° F (0-42° C)
Sprayer Dimensions
Lo-Boy
Height 28.0 in. 71.1 cm
Length (Handle Retracted) 29.5 in. 74.9 cm
Length (Handle Extended) 35.0 in. 88.9 cm
Width 22.3 in. 56.6 cm
Weight (sprayer, hose, gun) 90 lbs. 41 kg
Standard, 695 XT/795 XT/Mark IV XT
Height (Handle Retracted) 30.5 in. 77.5 cm
Height (Handle Extended) 40.2 in. 102.1 cm
Length 25.3 in. 64.3 cm
Width 22.3 in. 56.6 cm
695/795 Weight (sprayer, hose, gun) 93 lbs. 42 kg
Mark IV Weight (sprayer, hose, gun) 103 lbs. 47 kg
Standard, 1095 XT/Mark V XT/Mark VII XT
Height (Handle Retracted) 30.5 in. 77.5 cm
Height (Handle Extended) 40.2 in. 102.1 cm
Length 25.9 in. 65.8 cm
Width 24.4 in. 62.0 cm
1095 Weight (sprayer, hose, gun) 112 lbs. 51 kg
Mark V Weight (sprayer, hose, gun) 122 lbs. 55 kg
Mark VII Weight (sprayer, hose, gun) 126 lbs. 57 kg
ProContractor, 695 XT/795 XT/Mark IV XT
Height (Quick Reel Handle Vertical) 41.3 in. 104.9 cm
