Digital Display
3B0070C 35
Replacing BlueLink Battery
In order to keep your sprayer synced, your
unit has a small battery built-in. If you receive
the following message, the battery will need
to be replaced.
1. Turn sprayer OFF and unplug the power
cord.
2. Using T20 torx tool, remove two
screws and remove display board.
3. Slide battery out of the holder.
4. Replace battery with a new CR2032
battery.
5. Reinstall display board screws. Torque
to 12-16 in. lbs.
