Operation
3B0070C 25
Amp Switch
The 230V Mark VII units contain an amp
switch to switch the model from 10 to 16
amps.
The 100-120v 795, 1095, Mark IV, and Mark
V units contain an amp switch to switch the
model from 15 to 20 amps.
This switch is located to the right of the
power cord, as shown in the image.
Spray
When RAC X™ Low Pressure Switch Tips
(FFLP, LP and WRLP) are used, spraying
pressure can be lowered. Spraying at a lower
pressure results in less overspray and
reduces spray tip wear. Adjust the sprayer
pressure to minimize overspray.
1. Spray test pattern. Adjust pressure to
eliminate heavy edges.
2. Use smaller tip size if pressure
adjustment cannot eliminate heavy
edges.
3. Hold gun perpendicular, 10-12 in.
(25-30 cm) from surface. Spray back
and forth; overlap by 50%.
4. Trigger gun after moving. Release
trigger before stopping. For additional
spraying information, see separate gun
manual.
Spraying with atomized,
evenly distributed fan
pattern
Spraying with tails
