Parts
58 3B0070C
Digital Display
Digital Display Parts List
Ref. Torque Ref. Torque Ref. Torque
14 12-16 in-lb (1.4-1.8 N•m) 24 8-10 in-lb (0.9-1.1 N•m) 25 10-15 in-lb (1.1-1.7 N•m)
Ref. Part Description Qty.
42 2003288 SHIELD, motor, side,
includes 49, 59, 64
1
49 19C988 GROMMET, transducer 1
58 MODULE, display, includes
59
1
20B432 ProContractor/Bluelink
20B431 Display only
59 19D307 SCREW, mach., torx pan hd. 5
60 2003350 POTENTIOMETER, assy 1
61 15C973 GASKET 1
62 19C986 KNOB, potentiometer 1
63 19C527 HARNESS, display 1
64 19C998 LABEL, brand, control 1
83 19D678 LABEL, control 1
