Technical Data
46 3A4399A
Technical Data
695 Sprayers
U.S. Metric
Sprayer
Maximum Delivery 0.75 gpm 2.8 lpm
Maximum Tip Size 0.031 0.031
Fluid Outlet npt(f) 3/8 in.
Fluid Inlet 1-5/16-12 un(m)
Cycles 226 per gallon 60 per liter
Generator Minimum 5000 W 5000 W
230V, A, Hz 9, 50/60 9, 50/60
Dimensions
Weight: 111 lb 50 kg
Height: 39 in. 99 cm
Length: 22.5 in. 57.2 cm
Width:
Wetted parts
zinc- and nickel-plated carbon steel, nylon, stainless steel, PTFE, Acetal,
leather, UHMWPE, aluminum, tungsten carbide, PEEK, brass,
chrome plating, fluoroelastomer, polyethylene
Noise Level:
Sound Power 91 dBa* 91 dBa*
Sound Pressure 82 dBa* 82 dBa*
*per ISO 3744; measured at 3.1 ft *per ISO 3744; measured at 1 m
