Graco Fusion AP User Manual

Parts
309550ZAP 35
Detail Views
 Included in Spatter Tip Kit 248414.
 Included in Stud Wall Foam Kit 249421.
Flat Pattern Stud Wall Foam Detail
Flat Pattern Detail
Supplied Tools
4-Hose Fluid Manifold Detail
Flush Manifold
Splatter Tip Detail
61
63
64
62
19
10
39
40
19
53
43
54
50
12e
12d
12g
12b
12f
50
12f
12e
3
3
3
5
12d (Ref)
35 (Ref)
52
33 (Ref)
60
10
59
58
Torque to 125-135 in-lb
(14-15 N•m).
Torque to 235-245 in-lb
(26.6-27.7 N•m).
Torque to 32-40 ft-lb
(43-54 N•m).
1
3
5
TI2557A
TI3870A
TI4660C-1
TI7134A
TI4555B
TI2647A
3
1
1
Ref. Part Description Qty.
39 FTxxxx TIP, flat, see Flat Tip Kits, page 37 1
40 246360 O-RING, PTFE, flat tip models only;
package of 3; see Flat Tip Kits,
page 37
1
43 117661 VISE, pin, dual reversible chucks 1
52 15B817 MANIFOLD, gun flush; round and
flat pattern guns only
1
53 117642 NUT DRIVER, hex, 5/16 1
54 118575 SCREWDRIVER, 1/8 blade 1
58 15D972 RETAINER, tip, spatter pattern gun
only
1
59 15D971 TIP, spatter pattern gun only 1
60 248019 SEAL, package of 5, spatter pattern
gun only.
1
61 15F240 ADAPTER, stud wall 1
62 15F854 PACKING, tip, stud wall 1
63 15F241 CAP, air, stud wall 1
64 FTM979 TIP, flat, stud wall 1
10 15B801 AIR CAP, for flat pattern guns, not
included in Front End Replacement
Kit 24636
1
 15D973 AIR CAP, for spatter pattern gun, not
included in Front End Replacement
Kit 246361
1
Ref. Part Description Qty.
