Accessories
309550ZAP 41
Accessories
Fusion PC Conversion Kits
For converting the Fusion AP spray gun to a Fusion PC spray gun for use with ProConnect™ fluid cartridges. See
Related Manuals, page 3.
Round Pattern
Flat Pattern
Bare
NOTE: Bare conversion kits include the same accessories as standard conversion kits, without a mix chamber and
drill bits. A round air cap is provided.
Conversion
Kit
Mix Chamber
Part
Number
Impingement Port Size
in. (mm)
Equivalent
Size
Pattern at 24
in. (61 cm)
from target
in. (mm)
25P700 PC29RD 0.029 (0.70) 00 8 (203)
25R087 PC37RD 0.037 (0.94) 00-01 9 (227)
25P701 PC42RD 0.042 (1) 01 11 (279)
25P703 PC47RD 0.0469 (1.18) 01-02 11 (279)
25P702 PC52RD 0.052 (1.3) 02 12 (305)
25R088 PC60RD 0.060 (1.50) 03 14 (356)
Conversion
Kit
Mix Chamber Flat Tip
Part
Number
Impingement
Port Size
in. (mm)
Equivalent
Size
Part
Number
Pattern Size
in. (mm)
Orifice Size
in. (mm)
25R089 AF2929 0.029 (0.70) 00 FT0438 8-10 (203-254) 0.038 (0.97)
Conversion Kit
25P704
