Graco Fusion AP User Manual

Technical Specifications
309550ZAP 45
Technical Specifications
Air Flow by Mix Chamber
Fusion Air Purge Spray Gun
US Metric
Maximum Fluid Working Pressure 3500 psi 24.5 MPa, 245 bar
Minimum Air Inlet Pressure 80 psi 0.56 MPa, 5.6 bar
Maximum Air Inlet Pressure 130 psi 0.9 MPa, 9 bar
Air Flow Range
See chart below
Typical Flow Rate of Round Pattern Guns See Round Pattern Guns chart, page 4
Typical Flow Rate of Flat Pattern Guns See Flat Pattern Guns chart, page 5
Maximum Fluid Temperature 200° F 94° C
Air Inlet Size 1/4 npt Quick Disconnect Nipple
A Component (ISO) Inlet Size -5 JIC 1/2-20 UNF
B Component (Resin) Inlet Size -6 JIC 9/16-18 UNF
Dimensions 7.5 x 8.1 x 3.3 in. 191 x 206 x 84 mm
Weight 2.5 lb 1.1 kg
Wetted Parts
Aluminum, stainless steel, carbon steel, carbide,
chemically resistant o-rings
Noise
Maximum sound pressure
81.1 dB(A), using AR5252 at 100 psi (0.7 MPa, 7 bar)
Maximum sound power
91.0 dB(A), using AR5252 at 100 psi (0.7 MPa, 7 bar)
Sound power measured per ISO-9416-2.
Notes
All trademarks or registered trademarks are the property of their respective owners.
Air Pressure
(detriggered)
Mix Chamber Sizes (scfm (m
3
/min))
psi (MPa, bar) AR2020 AR2929 AR3737 AR4242 AR5252 AR6060 AR7070 AR8686
80 (0.56, 5.6)
0.8
(0.022)
1.4
(0.039)
2.0
(0.056)
2.6
(0.073)
3.7
(0.104)
4.6
(0.129)
5.7
(0.160)
7.1
(0.200)
100 (0.7, 7)
0.9
(0.025)
1.7
(0.048)
2.9
(0.081)
3.1
(0.087)
4.6
(0.129)
5.7
(0.160)
7.1
(0.200)
8.8
(0.246)
130 (0.9, 9)
1.2
(0.034)
2.3
(0.064)
3.2
(0.090)
4.1
(0.115)
5.9
(0.165)
7.3
(0.204)
9.2
(0.258)
11.3
(0.316)
