Graco Fusion AP User Manual

Models
309550ZAP 5
Flat Pattern Guns
Gun Part,
Series
Mix Chamber Flat Tip
Part
Number
Impingement
Port Size
in. (mm)
Equivalent
Size
Part
Number
Pattern Size
in. (mm)
Orifice Size
in. (mm)
247101, A AF2020 0.020 (0.50) -000 FT0424 8-10 (203-254) 0.024 (0.61)
247102, A AF2020 0.020 (0.50) -000 FT0438 8-10 (203-254) 0.038 (0.97)
247103, A AF2020 0.020 (0.50) -000 FT0624 12-14 (305-356) 0.024 (0.61)
247104, A AF2020 0.020 (0.50) -000 FT0638 12-14 (305-356) 0.038 (0.97)
247107, A AF2020 0.020 (0.50) -000 FT0838 16-18 (406-457) 0.038 (0.97)
247108, A AF2020 0.020 (0.50) -000 FT0848 16-18 (406-457) 0.048 (1.22)
247111, A AF2929 0.029 (0.70) -00 FT0424 8-10 (203-254) 0.024 (0.61)
247112, A AF2929 0.029 (0.70) -00 FT0438 8-10 (203-254) 0.038 (0.97)
247113, A AF2929 0.029 (0.70) -00 FT0624 12-14 (305-356) 0.024 (0.61)
247114, A AF2929 0.029 (0.70) -00 FT0638 12-14 (305-356) 0.038 (0.97)
247117, A AF2929 0.029 (0.70) -00 FT0838 16-18 (406-457) 0.038 (0.97)
247118, A AF2929 0.029 (0.70) -00 FT0848 16-18 (406-457) 0.048 (1.22)
247121, A AF4242 0.042 (1.00) -01 FT0424 8-10 (203-254) 0.024 (0.61)
247122, A AF4242 0.042 (1.00) -01 FT0438 8-10 (203-254) 0.038 (0.97)
247123, A AF4242 0.042 (1.00) -01 FT0624 12-14 (305-356) 0.024 (0.61)
247124, A AF4242 0.042 (1.00) -01 FT0638 12-14 (305-356) 0.038 (0.97)
247127, A AF4242 0.042 (1.00) -01 FT0838 16-18 (406-457) 0.038 (0.97)
247128, A AF4242 0.042 (1.00) -01 FT0848 16-18 (406-457) 0.048 (1.22)
247131, A AF5252 0.052 (1.30) -02 FT0424 8-10 (203-254) 0.024 (0.61)
247132, A AF5252 0.052 (1.30) -02 FT0438 8-10 (203-254) 0.038 (0.97)
247133, A AF5252 0.052 (1.30) -02 FT0624 12-14 (305-356) 0.024 (0.61)
247134, A AF5252 0.052 (1.30) -02 FT0638 12-14 (305-356) 0.038 (0.97)
247137, A AF5252 0.052 (1.30) -02 FT0838 16-18 (406-457) 0.038 (0.97)
247138, A AF5252 0.052 (1.30) -02 FT0848 16-18 (406-457) 0.048 (1.22)
