Parts
309550ZAP 37
Flat Pattern
Wide Pattern
Kits include mix chamber and cleanout drills. Spray guns with wide pattern mix chambers spray larger diameter
patterns than guns with the standard mix chambers.
Flat Tip Kits
Flat Tip Part Reference Guide
Example part number FT0848:
Flat Tip
Mix Chamber
Kit (includes
drill bits and
o-ring)
Nozzle Orifice
Size
Nozzle Drill
Bit Size,
in. (mm)
Impingement
Port Size
Impingement Port
Drill Bit Size,
in. (mm)
Counterbore
Size
Counterbore Drill
Bit Size,
in. (mm)
AF2020 0.094 3/32 (2.35) 0.020 #76 (0.50) 0.060 #53 (1.50)
AF2929 0.094 3/32 (2.35) 0.029 #69 (0.70) 0.060 #53 (1.50)
AF4242 0.094 3/32 (2.35) 0.042 #58 (1.00) N/A N/A
AF5252 0.094 3/32 (2.35) 0.052 #55 (1.30) N/A N/A
Non 1:1 Ratio Flat Mix Chamber Kits
Mix Chamber
Kit (includes
drill bits)
Nozzle Orifice
Size
Nozzle Drill
Bit Size,
in. (mm)
Impingement
Port Size
Impingement Port
Drill Bit Size,
in. (mm)
Counterbore
Size
Counterbore Drill
Bit Size,
in. (mm)
AF2033 0.094 3/32 (2.35) 0.035
0.021
#66, 0.033 (0.84)
#76 0.020 (0.51)
0.061 #53, 0.0595 (1.50)
AF2942 0.094 3/32 (2.35) 0.042
0.031
#58, 0.042 (1.07)
#69 0.029 (0.74)
0.061 #53, 0.0595 (1.50)
Kit
Pattern Diameter at 24 in.
(609.6 mm) to target
in. (mm)
Equivalent flow to
mix chamber size
Nozzle Drill Bit Size
in. (mm)
Impingement Drill Bit Size
in. (mm)
AW2222 8 (203.2) N/A 0.047 (1.20) #74, 0.022 (0.56)
AW2828 15 (381.0) AR2929 1/16, 0.062 (1.59) #70, 0.028 (0.71)
AW3333 15 (381.0) AR3737 #53, 0.060 (1.52) #66, 0.033 (0.84)
AW3939 16 (406.4) AR4242 #50, 0.070 (1.78) #61, 0.039 (0.99)
AW4646 18 (457.2) AR5252 0.085 (2.15) #56, 0.046 (1.17)
AW5757 18 (457.2) AR6060 #43, 0.089 (2.26) 1.45 mm, 0.057 (1.45)
AW6464 22 (563.9) AR7070 7/64, 0.109 (2.77) #52, 0.064 (1.63)
AW8282 24 (609.6) AR8686 1/8, 0.125 (3.18) #45, 0.082 (2.08)
FT 08 48
FT=Flat tip x2=pattern length
(8x2=16 in.)
Equivalent orifice
diameter size (0.048 in.)
Flat Spray Tip
(Ref. 39)
Pattern Size, in. (mm)
FT0424 low flow, 8-10 (203-254)
FT0438 medium flow, 8-10 (203-254)
FT0624 low flow, 12-14 (305-356)
FT0638 medium flow, 12-14 (305-356)
FT0838 medium flow, 16-18 (406-457)
FT0848 high flow, 16-18 (406-457)
