Graco GM 5000 Instructions-Parts List

41
308-327
Parts – Pressure Control
Part No. 222–369 – Basic Pressure Control for the
GM5000 Sprayers
Includes items 300 to 315 only .
Order the Basic Pressure Control 222–369,
and items 314 to 319 as required.
Ref.
No. Part No. Description Qty.
Ref.
No. Part No. Description Qty.
300
{ 222–380 PRESSURE CONTROL
Includes items 302 to 304 1
301Y 183–466
LABEL, warning 1
302
{ 105–679 ON/OFF SWITCH 1
303
{ 105–659 BOOT, switch 1
304
{ 107–255 GUARD, locking 1
305
{ 157–021 LOCKW ASHER, No. 8, internal 2
306{ 100–284 NUT , hex, msc 8–32 1
307
{ 108–219 RECTIFIER, bridge 1
308
{ 108–783 SCREW , mach, frhd 8–32 x
13/16
”1
309
{ 222–352 TRIAC ASSEMBLY 1
310{ 107–070 SCREW , flat head; csk hd 2
311
{ 100–072 NUT , hex 2
312
{ 103–181 LOCKWASHER 2
313
{ 220–979 CONDUCTOR, red 2
314
{ 100–035 SCREW , mach, slotted pan head;
No. 8 x 5/16” 1
315{ 101–754 PLUG, pipe 1
316 220–978 CONDUCT
OR, red, white, black 1
317 183–461
NIPPLE, hex; 3/8–18 npsm x 1/4–18 2
318 100–840 ELBOW, str
, 1/4–18 npt (m x f) 2
319 108–852 CONNECTOR, 45
_ 1
Y
Replacement Danger and W arning labels, tags and cards
are available at no cost.
{ Parts marked with a dagger are supplied with the basic
pressure control.
317
300{
304{
303{
302{
309{
313
310{
311{
312{
318
307{
308{,305{,306{
313
RED
BLACK
WHITE
RED
314{,305{
319
316
RED
GROUND
315{
0148
RECTIFIER (307) CONNECTIONS
0151
