42
308-327
Wiring
Schematic – Pressure Control
WHITE
RED
BLACK
WHITE
GROUND
RED
RED
MT2 MT1
G
R
CNO
0054
RED
RED
A
B
C
D
D
E
KEY
A Alternator
B Main
switch
C Rectifier
D
Clutch Field
E
Adjustable pressure switch
