Pressure Relief Procedure
3A5085C 11
If using a metal siphon cup:
5. Unlatch cup cover, loosen or remove cup
from cover to relieve pressure.
If using a ProComp remote cup:
6. Turn compressor ON/OFF switch to OFF
position.
7. Disconnect air hose from remote cup.
Turn out pressure regulator one turn.
Wait until pressure is completely
relieved before removing cover.
ti30628a
ti30892a
