Graco HVLP Series User Manual

Startup
3A5085C 17
Cup Over Installation
1. Perform Pressure Relief Procedure,
page 10.
2. Disconnect gun from FlexLiner system.
3. Loosen nut on backside of gun. Do not
remove nut. Pull nozzle housing
assembly out just far enough to allow
rotation. Rotate nozzle housing
assembly 180° so it faces upward.
ti30706a

Graco HVLP Series Specifications

General

Brand	Graco
Series	HVLP Series
Type	HVLP Paint Sprayer
Spray Technology	HVLP (High Volume Low Pressure)
Air Inlet Size	1/4 inch
Hose Length	N/A (Requires separate air hose)
