Graco HVLP Series User Manual

Parts
40 3A5085C
Parts
ProComp Models
5
1
2
3
4
3
2
2
2
6
2
7
4
2
2
3
3
1
Ref. Torque
110-115 in-lb (12.5 - 13.0 N•m)
20-25 in-lb (2.5 - 3.0 N•m)
15-20 in-lb (1.7 - 2.3 N•m)
10-15 in-lb (1.1 - 1.7 N•m)
35-40 in-lb (4.0 - 4.5 N•m)
5-8 in-lb (0.5 - 0.9 N•m)
20-23 ft-lb (28.0 - 31.0 N•m)
1
2
3
4
5
6
7

Graco HVLP Series Specifications

General

Brand	Graco
Series	HVLP Series
Type	HVLP Paint Sprayer
Spray Technology	HVLP (High Volume Low Pressure)
Air Inlet Size	1/4 inch
Hose Length	N/A (Requires separate air hose)
