Pressure Relief Procedure
10 3A5085C
Pressure Relief Procedure
Follow the Pressure Relief
Procedure whenever you see this
symbol.
1. Turn the ON/OFF switch to OFF
position.
Standard Models:
ProContractor and ProComp Models:
2. Unplug power cord to disconnect power.
3. Disconnect spray gun from air hose.
If using a FlexLiner System:
4. Disconnect tubing from gun to relieve
pressure in the cup.
The spray gun cup is pressurized. To
reduce the risk of splashing from
pressurized fluid, always follow the
Pressure Relief Procedure before
removing cup.
ti30625a
ti31188a
ti30757a
ti30627a

Graco HVLP Series Specifications

General

Brand	Graco
Series	HVLP Series
Type	HVLP Paint Sprayer
Spray Technology	HVLP (High Volume Low Pressure)
Air Inlet Size	1/4 inch
Hose Length	N/A (Requires separate air hose)
