Setup
12 3A5085C
Setup
When unpacking sprayer for the first time or
after long term storage, perform setup
procedure.
1. Connect air hose to sprayer. Hand
tighten.
2. If using a ProComp Model with remote
cup:
Connect gun air hose (V) to end of sprayer
are hose (M).
3. Connect power cord to sprayer power
connection.
4. Plug sprayer power cord into grounded
outlet.
NOTICE
For units with a whip hose, do not connect
whip hose directly to sprayer. Connect
whip hose to gun end.
NOTICE
The AutoStart feature on ProContractor
and ProComp models relies on an air tight
system. Use components provided with
sprayer and Edge II Plus gun. Ensure all
hose connections are secure to avoid air
leakage.
ti30894a
ti30682a
