Graco HVLP Series User Manual

Startup
16 3A5085C
b. Tighten nut.
4. Latch cup cover to siphon cup.
5. Connect sprayer air hose to air inlet of
gun.
6. You are now ready to spray. Reference
How to Spray, page 22.
ti30942a
ti30943a
ti30944a

Graco HVLP Series Specifications

General

Brand	Graco
Series	HVLP Series
Type	HVLP Paint Sprayer
Spray Technology	HVLP (High Volume Low Pressure)
Air Inlet Size	1/4 inch
Hose Length	N/A (Requires separate air hose)
