Graco HVLP Series User Manual

Startup
3A5085C 21
If using FlexLiner System:
4. Point gun into a waste area. Evacuate air
from FlexLiner System by holding gun
vertically and pull trigger open until a
continuous spray pattern is observed.
NOTE: Tilt gun back and forth to help in
evacuation of air.
If using remote cup with ProComp Model:
5. Turn pressure regulator to lowest
setting.
6. Turn compressor ON/OFF switch to ON
position.
NOTE: If experiencing low remote cup
pressure, disconnect clear air hose from
compressor outlet (see step 2, page 15) and
allow compressor to run for 10 seconds.
Reconnect air hose.
ti30687a
ti30904a
ti30892a

Graco HVLP Series Specifications

General

Brand	Graco
Series	HVLP Series
Type	HVLP Paint Sprayer
Spray Technology	HVLP (High Volume Low Pressure)
Air Inlet Size	1/4 inch
Hose Length	N/A (Requires separate air hose)
