Technical Specifications
3A5085C 45
HVLP 7.0/9.0/9.5 ProContractor
US Metric
7.0
Maximum Amperage 11.0 6,0
Watts 1200
Electrical Power Requirement 120 VAC, 50/60 Hz,15A 220-240 VAC, 50/60Hz,10A
Maximum Hose Length 40 ft 12,2 m
Sprayer Weight 23 lb 10,4 kg
Total Weight 33 lb 15,0 kg
Noise* (dBa)
Sound pressure 82 dBa
Sound power 94.9 dBa
9.0
Maximum Amperage 12.0 6,5
Watts 1300
Electrical Power Requirement 120 VAC, 50/60 Hz,15A 220-240 VAC, 50/60Hz,10A
Maximum Hose Length 60 ft 18,3 m
Sprayer Weight 24 lb 10,9 kg
Total Weight 34 lb 15,4 kg
Noise* (dBa)
Sound pressure 83.0 dBa
Sound power 95.9 dBa
9.5
Maximum Amperage 13.5 8,0
Watts 1600
Electrical Power Requirement 120 VAC, 50/60 Hz,15A 220-240 VAC, 50/60Hz,10A
Maximum Hose Length 60 ft 18,3 m
Sprayer Weight 26 lb 11,8 kg
Total Weight 36 lb 16,3 kg
Noise* (dBa)
Sound pressure 83.4 dBa
Sound power 96.3 dBa
Materials of Construction
Wetted materials on all models zinc- and nickel-plated carbon steel, nylon, stainless steel,
PTFE, Acetal, leather, UHMWPE, aluminum, tungsten
carbide, polyethylene, fluoroelastomer, urethane
Notes
*Sound pressure measured 3 feet (1 meter) from equipment. Sound power
measured per ISO-3744.
