Technical Specifications
62 3A3426EOperation
Wetted Parts: PTFE, Nylon, polyurethane, V-Max,
UHMWPE, fluoroelastomer, acetal, leather, tungsten
carbide, stainless steel, chrome plating, nickel-plated
carbon steel, ceramic
LineLazer V 200HS HP Auto Series (Models 17K582, 17H462, 17K637, 17H463,17K583, 17H464)
U.S. Metric
Dimensions
Height (with handle bar down)
Unpackaged - 44.5 in.
Packaged - 52.5 in.
Unpackaged - 113.03 cm
Packaged - 133.35 cm
Width Unpackaged - 34.25 in.
Packaged - 37.0 in.
Unpackaged - 87.0 cm
Packaged - 93.98 cm
Length (with platform down)
Unpackaged - 68.75 in.
Packaged - 73.5 in.
Unpackaged - 174.63 cm
Packaged - 186.69 cm
Weight (dry - no paint) Unpackaged - 322 lbs
Packaged - 389 lbs
Unpackaged - 146 kg
Packaged - 176 kg
Noise (dBa)
Sound Power per ISO 3744:
103.1
Sound Pressure measured at 3.3 feet (1m):
86.5
Vibration (m/s
2
) (8 hours daily exposure)
Hand Arm (per ISO 5349)
1.6
Whole Body (per ISO 2631)
0.4
Power Rating (Horse Power)
Power Rating (Horse Power) per SAE J1349
6.5 HP @ 3600 rpm 4.84 kW @ 3600 rpm
Maximum Delivery
2.15 gpm 8.14 lpm
Maximum Tip Size
1 gun
2 gun
.047
.034
Inlet paint strainer 16 mesh 1190 micron
Outlet paint strainer 50 mesh 297 micron
Pump inlet size 1 in. NSPM (m)
Pump outlet size 3/8 NPT (f)
Maximum working pressure 3300 psi 228 bar, 22.8 MPa
Maximum fluid working pressure 3300 psi 228 bar, 22.8 MPa
Maximum free-flow delivery 2.15 gpm 8.14 lpm
Cycles per gallon/liter 62 cpg 16.4 cpl
Hydraulic reservoir capacity 1.25 gallons 4.73 liters
Hydraulic pressure 1825 psi 124 bar
Electrical Capacity 84 W@ 3600 rpm
Battery 12V, 22Ah, Sealed lead acid, Deep cycle
